Smoke Detector Built

Basic Info.

Model NO.	501
Anti-Theft Alarm System-Wide	Wireless Alarm Detector
Anti-Theft Alarm System Distance	Common Detectors
Types of Smoke Detectors	Ionization Smoke Style
Transport Package	Carton or Box
Trademark	tuotian
Origin	China

Product Description

Product parameter

product name	Wireless smoke alarm detector
Alarm sound pressure	≥ 85dB / M
Power supply	two No. 5 batteries
Working voltage	dc3v
Operating temperature	- 10 ºC - + 50 ºC
Static current	≤ 20ua
Working temperature	≤ 95%
Alarm current	≤ 35mA

Professional fire alarm fire guard
730 day real-time monitoring , safe and reliable
Smoke alarm is suitable for families , hotels , office buildings ,factories , warehouses and other scenesIt is widely used for fire prevention in many places such as home environment , schools , shopping , malls , factories , companies ,warehouses , KTV , community , chemical industry and so on

Smoke alarm principle

When the smoke exceeds the set standard value, the LED indicator flashes and the buzzer rings. If the smoke has not dissipated, the alarm will continue to alarm until the smoke has dissipated or the self-test button is pressed

85 db high tone alarm

So loud that the whole room can hear

After the alarm issued a strong sound, timely remind you of the alarm situation

730 day security guard

Under normal conditions, the battery life can be up to 2 years. When the battery of the alarm is under voltage, pressing the self-test button can give an audible and visual alarm prompt, that is, the replacement is successful

Installation method

Ceiling mounting
Smoke, heat and combustion products will spread horizontally when they rise to the ceiling.The alarm is recommended to be installed in the middle of the ceiling. Please keep a unit distance of at least 30cm from lamps or decorations and at least 15cm away from walls and corners. If the hall exceeds 12M, it shall be installed at both ends of the hall

Warm tips (TPS)

1.	Please do not install the alarm in a place with high temperature, high humidity and dust, and keep the air around the alarm fresh
2.	It is not necessary to install the alarm in a place where there are a lot of paint, diluents and other substances that produce colloidal suspension, so as not to affect the normal monitoring of the alarm area
3.	This product is a photoelectric smoke fire detection alarm, which can send out audible and visual alarm prompt in case of fire, but cannot play the function of fire extinguishing
4.	After the alarm is installed, press the self-test button every month to test. If any fault is found, it shall be handled in time
5.	Under normal conditions, the battery life can be up to 2 years, but the battery life will be shortened if it is used in high temperature, Gaozhou and other environments
6.	When the battery of the alarm is under voltage, please replace the battery of the same model in time. After replacement, press the self-test button to give an audible and visual alarm prompt, which means the replacement is successful.
7.	The alarm shall be installed immediately before commissioning. Before installation, it shall be properly protected and corresponding dust-proof, moisture-proof and corrosion prevention measures shall be taken.
8.	For other problems after the old tube alarm fails to be supplied, please do not disassemble it for maintenance without permission. Disconnect the electric tester and contact the local dealer for after-sales treatment

9	It is recommended to replace the new battery after the fire is investigated and the alarm department gives an alarm (in case of water fire, the alarm intelligence will always give an alarm until the smoke is dispersed or the power is lost
